| Рама |
Felt Q26 series 26" wheel MTB design, Dynaform 6061 aluminum for suspension fork, 1-1/8" head tube, forged dropout, w/ IS disc brake mounts |
| Вилка |
SR Suntour SF13-M3020, forged aluminum crown, one piece aluminum lower and brace w/IS disc mounts, preload adjust, 75mm travel |
| Задний амортизатор |
n/a |
| Размеры рам |
26" x S (13.5") M (16.5") L (19") XL (21.5") |
| Манетки |
Shimano 21 speed Revo shift levers: 7 speed right side, 3 speed left side with gear display |
| Передний переключатель |
Shimano FD-M191 top swing 7/8 speed |
| Задний переключатель |
Shimano Altus, Smart cage 7/8 speed: direct attachment |
| Система |
Forged aluminum 3-piece crank, melt-forged aluminum arms, 48/38/28t: steel/steel/steel, w/chainguard, capless axle bolts, lengths: S-170mm,M/L/XL-175mm |
| Каретка |
Sealed cartridge |
| Кассета |
Sunrace spin-on freewheel: 7-speed. 13-34t |
| Цепь |
KMC Z51 7-speed |
| Педали |
Steel cage w/pp body |
| Обода |
Doublewall aluminum for disc-brake, 32h |
| Спицы |
stainless 14g with brass nipples |
| Передняя втулка |
forged aluminum 6-bolt disc mount 32h hub: w/ aluminum quick release |
| Задняя втулка |
forged aluminum 6-bolt disc mount, spin-on freewheel type 7 speed, 32h hub: w/ aluminum quick release lever |
| Передняя покрышка |
Felt THC XC tire: Trail Highway City 26 x 2.1 30tpi wire wead, w/ Shraeder valve tubes |
| Задняя покрышка |
Felt THC XC tire: Trail Highway City 26 x 2.1 30tpi wire wead, w/ Shraeder valve tubes |
| Передний тормоз |
Дисковые механические, Tektro Novella mechanical disc brake 180mm front/ 160mm rear stainless steel rotors |
| Задний тормоз |
Дисковые механические, Tektro Novella mechanical disc brake 180mm front/ 160mm rear stainless steel rotors |
| Тормозные ручки |
Tektro TS360A MTB levers for linear pull brakes, 2 finger lever with return spring and reach adjust |
| Грипсы |
Felt MTB design: single density color matched |
| Руль |
Felt aluminum riser bar 30mm Rise, 9 degree Bend, w/ Felt logos. Widths S-600mm, M-620mm,L/XL-640mm |
| Вынос |
Felt One-piece heat treated aluminum design: 1-1/8" threadless aluminum, 4-bolt, 15 degree rise. 25.4mm bar bore. Extensions: S-70mm, M-90mm, L/XL-105mm |
| Рулевая колонка |
Semi-integrated 1-1/8" Aheadset steel cups, caged bearing, w/ felt Tornado aluminum top cap, custom curved 1 x 15mm + 2 x 5mm straight washers |
| Седло |
Felt mountain design low profile look w/ comfort fit top, double-density base, satin steel rails |
| Подседельный штырь |
Felt aluminum micro adjust 6061 aluminum shaft, low-profile forged head & extruded rail clamps, Sizes: S-27.2mm x 350mm, M/L/XL - 27.2mm x 400mm |
