| Рама |
Алюминий 6061, Felt QX-S design, double butted aluminum semi sloping Dynaform top tube Dynafom seatstays and chainstays. Integrated Kickstand and Basta lock mount, disc brake specific. |
| Вилка |
Масляно-пружинная, SR Suntour SF10-NVX-D HLO w/ hydraulic lockout 75mm travel, coil spring, preload, alloy Lower, 25.4mm stanchions, straight leg design, Integrated headset crown, disc brake specific lowers |
| Размеры рам |
44, 48, 52, 55, 58cm |
| Вес |
13.33 килограмм |
| Манетки |
Shimano Deore SL-M590 9 Speed Rapid Fire |
| Передний переключатель |
Shimano Deore FD- M590 top swing |
| Задний переключатель |
Shimano Deore, FD-M592 Shadow, long cage 9 Speed |
| Шатуны (система) |
Shimano FC-M521 9-speed forged Aluminum for Octalink bottom bracket, 48/36/26T, w/Chainguard, 44cm-52cm=170mm; 55cm/58cm=175mm |
| Каретка |
BB-ES25 Octalink |
| Кассета (трещотка): |
Sram PG-950 9-speed 11-32T |
| Цепь |
Sram PC-951 9-speed |
| Педали |
VP-199 w/ alloy body and Cage |
| Обода |
Двойные, WTB Dual Duty XC doublewall aluminum |
| Спицы |
stainless double butted 14g/15g w/ alloy nipples |
| Передняя втулка |
Shimano HB-M435 Centerlock rotor mount 36 hole, w/ Shimano quick release lever |
| Задняя втулка |
Shimano FH-M435 Centerlock rotor mount 8/9 speed cassette 36 hole, w/ Shimano quick release lever |
| Передняя покрышка |
Felt QX Cross design 700 x 37 60tpi wire bead, w/ Presta Valve tubes |
| Задняя покрышка |
Felt QX Cross design 700 x 37 60tpi wire bead, w/ Presta Valve tubes |
| Передний тормоз |
Дисковые гидравлические, Shimano BR-M446 hydraulic disc brake SM- RT53 160mm front/rear Centerlock rotors |
| Задний тормоз |
Дисковые гидравлические, Shimano BR-M446 hydraulic disc brake SM- RT53 160mm front/rear Centerlock rotors |
| Тормозные ручки |
Shimano BL-M505 |
| Грипсы |
Felt Ergo Grip Dual-Density Kraton Rubber w/ Ergonomic design |
| Руль |
Felt MTB design butted alloy riser bar 30mm rise, 8 degree bend, 4 degree up sweep, 25.4mm diameter. Widths 44cm - 49cm= 580mm 52-58cm=620mm |
| Вынос |
Felt MTB 3D-forged design 4-bolt handlebar clamp, 1-1/8"" threadless, for 25.4mm handlebar, 7 degree rise, w/ CP Cromo hardware Sizes; 44/48cm =80mm 49/52cm =90mm 55/58cm =110mm |
| Рулевая колонка |
Semi-integrated 1-1/8"" Aheadset Steel Cups, Caged Bearing, w/ Felt Tornado alloy top cap, custom curved 1 x 15mm + 2 x 5mm straight washers |
| Седло |
Felt mountain design low side profile look w/ comfort fit top, double-density base, Cromo rails |
| Подседельный штырь |
Felt 6061 alloy post twin clamp micro adjust 6061 alloy, low-profile forged head & extruded rail clamps, 27.2 x 350mm |
