| Рама |
FELT Nine series 29’er frame, butted 6061 aluminum w/ Dynaform top tube and seat stays, forged dropouts, oversized integrated head tube, rack & fender mounts, disc brake specific |
| Вилка |
SR Suntour SF13-XCT 29, forged/CNC Aluminum 6061 crown, one-piece aluminum lower w/ IS disc mounts , preload adjust, 100mm travel |
| Задний амортизатор |
Без заднего амортзитора |
| Размеры рам |
29" x XS(14"), S(16"), M(18"), L(20"), XL(22") |
| Манетки |
Sram X-4 triggers 8 speed |
| Передний переключатель |
Shimano FD-M310 top swing |
| Задний переключатель |
Sram X-4 Med cage 8 speed |
| Система |
SR Suntour CW13-XCT-V2-T312: PBG crankset: w/ forged aluminum arms 8-speed w/ interchangable 42X32X24T chainrings, lengths: XS/S-170mm,M/L/XL-175mm |
| Каретка |
Sealed cartridge |
| Кассета |
Sunrace CSM668 8-speed: 11-32t |
| Цепь |
KMC Z72 8-speed |
| Педали |
Steel cage w/pp body |
| Обода |
29" Doublewall aluminum for disc-brake, 32h |
| Спицы |
stainless 14g with brass nipples |
| Передняя втулка |
forged aluminum 6-bolt disc mount 32h hub: w/ aluminum quick release |
| Задняя втулка |
forged aluminum 6-bolt disc mount, 8-speed cassette 32h hub: w/ aluminum quick release lever |
| Передняя покрышка |
Geax AKA 2.2 wire bead w/ Shraeder valve tubes |
| Задняя покрышка |
Geax AKA 2.2 wire bead w/ Shraeder valve tubes |
| Передний тормоз |
Дисковые механические, Tektro Novella mechanical disc brake 180mm front/ 160mm rear stainless steel rotors |
| Задний тормоз |
Дисковые механические, Tektro Novella mechanical disc brake 180mm front/ 160mm rear stainless steel rotors |
| Тормозные ручки |
Tektro TS360A MTB levers for linear pull brakes, 2 finger lever with return spring and reach adjust |
| Грипсы |
Felt dual-density wing grips Kraton rubber base, Pruven rubber center, Color matched |
| Руль |
Felt MTB XC riser bar: butted 6061 Aluminum 30mm rise, 9 degree bend, 5 degree up sweep 31.8mm bar bore, Widths: XS-640mm, S/XL-680mm |
| Вынос |
Felt MTB 3D-forged design: 4-bolt handlebar clamp, 1-1/8" threadless, for 31.8mm handlebar, 7 degree rise, w/ CP Cromo hardware, Sizes; XS-80mm, S/M-90mm, L-100mm,XL-110mm |
| Рулевая колонка |
Semi-integrated 1-1/8" Aheadset steel cups, caged bearing, w/ felt Tornado aluminum top cap, custom curved 1 x 15mm + 2 x 5mm straight washers |
| Седло |
Felt mountain design low profile look w/ comfort fit top, double-density base, satin steel rails |
| Подседельный штырь |
Felt aluminum micro adjust 6061 aluminum shaft, low-profile forged head & extruded rail clamps, Sizes: XS/S-30.9mm x 350mm, M/L/XL - 30.9mm x 400mm |
