| Рама |
FELT Nine series 29’er frame, double butted 6061 aluminum w/ tapered head tube, Hydroform top tube and seat stays, forged dropouts, oversized integrated head tube, rack & fender mounts, disc brake specific |
| Вилка |
SR Suntour SF13 Raidon RL-29, tapered aluminum steerer tube, forged/CNC aluminum crown, magnesium disc specific lower w/ postmount disc mount, 32mm cro-mo hard chrome stanchions, adjustable air spring, speed lock, external rebound adjuster, 100mm travel |
| Задний амортизатор |
Без заднего амортзитора |
| Размеры рам |
29" x XS(14"), S(16"), M(18"), L(20"), XL(22") |
| Манетки |
Shimano Deore SL-M591 10 speed Rapid Fire |
| Передний переключатель |
Shimano Deore FD-M590-10 top swing |
| Задний переключатель |
Shimano Deore FD-M593 Shadow, long cage 10 Speed |
| Система |
Shimano Deore FC-M590 10 speed Hollowtech II 42X32X24T chainrings, lengths: XS/S-170mm, M/XL-175mm |
| Каретка |
w/ crankset |
| Кассета |
Shimano HG-62 10 Speed 11-36T |
| Цепь |
Shimano HG-54 10 Speed |
| Педали |
VP-331A w/ aluminum body and Cage |
| Обода |
WTB SX-17 29" disc brake doublewall aluminum, w/eyelets |
| Спицы |
stainless 14g w/ aluminum nipples |
| Передняя втулка |
Shimano HB-RM35 Centerlock disc hub w/ Shimano quick release |
| Задняя втулка |
Shimano FH-RM35 Centerlock rotor mount 8/9 speed cassette 32 hole, w/ Shimano quick release lever |
| Передняя покрышка |
Continental X-King SL 29" 2.2 w/ folding bead, Presta valve tubes |
| Задняя покрышка |
Continental X-King SL 29" 2.2 w/ folding bead, Presta valve tubes |
| Передний тормоз |
Дисковые гидравлические, Avid Elixir 1 hydraulic disc brake: w/180mm front/160mm rear rotors |
| Задний тормоз |
Дисковые гидравлические, Avid Elixir 1 hydraulic disc brake: w/180mm front/160mm rear rotors |
| Тормозные ручки |
Avid Elixir 1 |
| Грипсы |
Felt dual-density wing grips Kraton rubber base, Pruven rubber center, Color matched |
| Руль |
Felt MTB XC riser bar: double butted 6061 Aluminum 25mm rise, 9 degree bend, 5 degree up sweep 31.8mm bar bore, Widths: XS-640mm, S/M-680mm, L/XL-700mm |
| Вынос |
Felt MTB 3D-forged design: 4-bolt handlebar clamp, 1-1/8" threadless, for 31.8mm handlebar, 7 degree rise, w/ CP Cromo hardware, Sizes; XS-80mm, S/M-90mm, L-100mm,XL-110mm |
| Рулевая колонка |
Semi-Integrated 1-1/8"/1.5" Aheadset for tapered head tube: Steel cups, caged bearings, w/ Felt Tornado aluminum top cap, custom curved 1 x 15mm + 2 x 5mm straight washers |
| Седло |
Felt mountain design low profile look w/ comfort fit top, double-density base, satin steel rails |
| Подседельный штырь |
Felt aluminum 2-bolt micro adjust butted 6061 aluminum shaft, low-profile forged head & forged rail clamps, Sizes: S-30.9mm x 350mm, M/L/XL - 30.9mm x 400mm |
